Commercial Duty · EN 1433

Tec V Series
Talk to a specialist

Without slope (0%)

Standard / flat bottom

Flexible drain placement

Identification

Element height code

no. 0 – 5

Element length

1 m (39.4")

Nominal width

NW 100 (4")

Dimensions (element no. 0)

Overall width

162 mm (6.4")

Interior width

100 mm (3.9")

Installation height

120 mm (4.7")

Weight

~9.5 kg (~20.9 lb)

Hydraulics

Internal slope

0%

Flow direction

Toward outlet point

Outlet

Vertical, pre-formed

Key feature

Outlet position

Any element in run

Slope by terrain

Required externally

Run length flexibility

High

Open products

0.5% internal slope

Built-in fall

Cascading step system

Identification

Element height code

no. 0 → 1 → 2 → … → 20

Element length

1 m (39.4")

Nominal width

NW 100 (4")

Dimensions (element no. 0)

Overall width

162 mm (6.4")

Interior width

100 mm (3.9")

Installation height

120 → 145 mm (4.7"→5.7")

Weight

~9.5 kg (~20.9 lb)

Hydraulics

Internal slope

0.5%

Flow direction

Built-in toward outlet

Outlet

End of sloped run

Key feature

Step height per element

2.5 mm / 500 mm

Slope by terrain

Not required

Self-cleaning effect

Enhanced

Open products

Channel body

Width (in) Image Product Name No Size Weight Load class Edge type
4" BG-FILCOTEN tec V NW 100 No. 0, with galvanized steel edge, without slope | 10410200 BG-FILCOTEN tec V NW 100 No. 0, with galvanized steel edge, without slope | 10410200 10410200

length:

height:

width:

13.42 kg C250 galvanized steel
4" BG-FILCOTEN tec V NW 100 No. 5-0, with galvanized steel edge, without slope | 10410261 BG-FILCOTEN tec V NW 100 No. 5-0, with galvanized steel edge, without slope | 10410261 10410261

length:

height:

width:

16.1 kg C250 galvanized steel
4" BG-FILCOTEN tec V NW 100 No. 10-0, with galvanized steel edge, without slope | 10410262 BG-FILCOTEN tec V NW 100 No. 10-0, with galvanized steel edge, without slope | 10410262 10410262

length:

height:

width:

18.7 kg C250 galvanized steel
4" BG-FILCOTEN tec V NW 100 No. 10, with galvanized steel edge, 0,5% slope | 10410210 BG-FILCOTEN tec V NW 100 No. 10, with galvanized steel edge, 0,5% slope | 10410210 10410210

length:

height:

width:

18.5 kg C250 galvanized steel
4" BG-FILCOTEN tec V NW 100 No. 1, with galvanized steel edge, 0,5% slope | 10410201 BG-FILCOTEN tec V NW 100 No. 1, with galvanized steel edge, 0,5% slope | 10410201 10410201

length:

height:

width:

13.4 kg C250 galvanized steel
4" BG-FILCOTEN tec V NW 100 No. 2, with galvanized steel edge, 0,5% slope | 10410202 BG-FILCOTEN tec V NW 100 No. 2, with galvanized steel edge, 0,5% slope | 10410202 10410202

length:

height:

width:

14.1 kg C250 galvanized steel
4" BG-FILCOTEN tec V NW 100 No. 3, with galvanized steel edge, 0,5% slope | 10410203 BG-FILCOTEN tec V NW 100 No. 3, with galvanized steel edge, 0,5% slope | 10410203 10410203

length:

height:

width:

14.8 kg C250 galvanized steel
4" BG-FILCOTEN tec V NW 100 No. 4, with galvanized steel edge, 0,5% slope | 10410204 BG-FILCOTEN tec V NW 100 No. 4, with galvanized steel edge, 0,5% slope | 10410204 10410204

length:

height:

width:

15.4 kg C250 galvanized steel
4" BG-FILCOTEN tec V NW 100 No. 5, with galvanized steel edge, 0,5% slope | 10410205 BG-FILCOTEN tec V NW 100 No. 5, with galvanized steel edge, 0,5% slope | 10410205 10410205

length:

height:

width:

15.9 kg C250 galvanized steel
4" BG-FILCOTEN tec V NW 100 No. 6, with galvanized steel edge, 0,5% slope | 10410206 BG-FILCOTEN tec V NW 100 No. 6, with galvanized steel edge, 0,5% slope | 10410206 10410206

length:

height:

width:

16.4 kg C250 galvanized steel
4" BG-FILCOTEN tec V NW 100 No. 7, with galvanized steel edge, 0,5% slope | 10410207 BG-FILCOTEN tec V NW 100 No. 7, with galvanized steel edge, 0,5% slope | 10410207 10410207

length:

height:

width:

16.8 kg C250 galvanized steel
4" BG-FILCOTEN tec V NW 100 No. 8, with galvanized steel edge, 0,5% slope | 10410208 BG-FILCOTEN tec V NW 100 No. 8, with galvanized steel edge, 0,5% slope | 10410208 10410208

length:

height:

width:

17.4 kg C250 galvanized steel
4" BG-FILCOTEN tec V NW 100 No. 9, with galvanized steel edge, 0,5% slope | 10410209 BG-FILCOTEN tec V NW 100 No. 9, with galvanized steel edge, 0,5% slope | 10410209 10410209

length:

height:

width:

18.0 kg C250 galvanized steel
4" BG-FILCOTEN tec V NW 100 No. 11, with galvanized steel edge, 0,5% slope | 10410211 BG-FILCOTEN tec V NW 100 No. 11, with galvanized steel edge, 0,5% slope | 10410211 10410211

length:

height:

width:

20.55 kg C250 galvanized steel
4" BG-FILCOTEN tec V NW 100 No. 12, with galvanized steel edge, 0,5% slope | 10410212 BG-FILCOTEN tec V NW 100 No. 12, with galvanized steel edge, 0,5% slope | 10410212 10410212

length:

height:

width:

20.9 kg C250 galvanized steel
4" BG-FILCOTEN tec V NW 100 No. 13, with galvanized steel edge, 0,5% slope | 10410213 BG-FILCOTEN tec V NW 100 No. 13, with galvanized steel edge, 0,5% slope | 10410213 10410213

length:

height:

width:

21.3 kg C250 galvanized steel
4" BG-FILCOTEN tec V NW 100 No. 14, with galvanized steel edge, 0,5% slope | 10410214 BG-FILCOTEN tec V NW 100 No. 14, with galvanized steel edge, 0,5% slope | 10410214 10410214

length:

height:

width:

22.9 kg C250 galvanized steel
4" BG-FILCOTEN tec V NW 100 No. 15, with galvanized steel edge, 0,5% slope | 10410215 BG-FILCOTEN tec V NW 100 No. 15, with galvanized steel edge, 0,5% slope | 10410215 10410215

length:

height:

width:

23.1 kg C250 galvanized steel
4" BG-FILCOTEN tec V NW 100 No. 16, with galvanized steel edge, 0,5% slope | 10410216 BG-FILCOTEN tec V NW 100 No. 16, with galvanized steel edge, 0,5% slope | 10410216 10410216

length:

height:

width:

23.8 kg C250 galvanized steel
4" BG-FILCOTEN tec V NW 100 No. 17, with galvanized steel edge, 0,5% slope | 10410217 BG-FILCOTEN tec V NW 100 No. 17, with galvanized steel edge, 0,5% slope | 10410217 10410217

length:

height:

width:

24.1 kg C250 galvanized steel
4" BG-FILCOTEN tec V NW 100 No. 18, with galvanized steel edge, 0,5% slope | 10410218 BG-FILCOTEN tec V NW 100 No. 18, with galvanized steel edge, 0,5% slope | 10410218 10410218

length:

height:

width:

26.9 kg C250 galvanized steel
4" BG-FILCOTEN tec V NW 100 No. 19, with galvanized steel edge, 0,5% slope | 10410219 BG-FILCOTEN tec V NW 100 No. 19, with galvanized steel edge, 0,5% slope | 10410219 10410219

length:

height:

width:

28.0 kg C250 galvanized steel
4" BG-FILCOTEN tec V NW 100 No. 20, with galvanized steel edge, 0,5% slope | 10410220 BG-FILCOTEN tec V NW 100 No. 20, with galvanized steel edge, 0,5% slope | 10410220 10410220

length:

height:

width:

27.7 kg C250 galvanized steel
4" BG-FILCOTEN tec V NW 100 No. 20-0, with galvanized steel edge, without slope | 10410264 BG-FILCOTEN tec V NW 100 No. 20-0, with galvanized steel edge, without slope | 10410264 10410264

length:

height:

width:

27.7 kg C250 galvanized steel

gratings

Image Product Name Load class Features Inlet cross-section (cm²/m) Weight Item no.
Composite slotted grating NW 100, 1000/122/2, SW 8/80, cl. B125 | 17010403 Composite slotted grating NW 100, 1000/122/2, SW 8/80, cl. B125 | 17010403 B 125 0.0 kg 17010403
ductile iron bar grating NW 100, 500/122/20, MW 28/9, cl. D400 (tec, pro) | 17010110 ductile iron bar grating NW 100, 500/122/20, MW 28/9, cl. D400 (tec, pro) | 17010110 D400 0.0 kg 17010110
ductile iron bar grating NW 100, 500/122/20, MW 29/6, cl. C250 (pro) fiX | 17010106 ductile iron bar grating NW 100, 500/122/20, MW 29/6, cl. C250 (pro) fiX | 17010106 C250 0.0 kg 17010106

accessories

Image Product Name Item no Features Weight
anti-vandalism locking device NW 100 (BG-FILCOTEN tec, pro) | 32087 anti-vandalism locking device NW 100 (BG-FILCOTEN tec, pro) | 32087 32087 0.0 kg
Installation chair kit NW100, BG-FILCOTEN self/light/tec/pro NW100, galvanized | 19010902 Installation chair kit NW100, BG-FILCOTEN self/light/tec/pro NW100, galvanized | 19010902 19010902 0.0 kg
step displace plate NW 100, Nr. 0-20/0, galvanized (light, tec, pro) | 19010295 step displace plate NW 100, Nr. 0-20/0, galvanized (light, tec, pro) | 19010295 19010295 0.0 kg
no hub bottom outlet plate NW 100, with outlet, 4", galvanized (pro V) | 19011204 no hub bottom outlet plate NW 100, with outlet, 4", galvanized (pro V) | 19011204 19011204 0.0 kg
BG-FILCOTEN front-/end plate plastic, NW 100, DN100 | 19010400 BG-FILCOTEN front-/end plate plastic, NW 100, DN100 | 19010400 19010400 0.0 kg
BG-FILCOTEN tec KIT NW 100 V, sump unit with galv. steel edge, silt bucket, pipe coupl. DN 150 | 10410294 BG-FILCOTEN tec KIT NW 100 V, sump unit with galv. steel edge, silt bucket, pipe coupl. DN 150 | 10410294 10410294 0.0 kg
Tec V Series

BG-FILCOTEN
tec V
Load class
E 600
NW 100 mm (4")

Variants: without slope, outlet without slope

CO2-eq: 2.6 , 3.3 , 7.1 Kg/piece

Edge -

Material: FILCOTEN HPC

Length: 1,000mm (39.4")

Width: 130 mm (5.2")

Height at channel end: 135 - 245 mm (5.4 - 9.7")
More details

Application areas: Platform, Facade, Airport (landside), Pedestrian zones, Landscape construction, Garage driveway Garden and landscape construction, Driveway Parking deck, Parking (car), Residential garage, Multi-storey car park, Pavers, Cycling routes, Slot top, Slot channel, Swimming pool, Sports facility, Terrace, Underground car park, Unobtrusive drainage, Garage, Design, Discreet drainage

Ready to Build Better?

Discover how BG-FILCOTEN® HPC can elevate your next drainage or construction project.
Request Technical Data Shop now
